Product Information
The AMP-PNMK plenum kit connects AC power to the IEC C14 AC power inlet of a compatible Crestron X-Series audio amplifier, allowing the amplifier to meet necessary plenum rating requirements.
Overview
The AMP-PNMK plenum kit connects AC power to the IEC C14 AC power inlet of a compatible Crestron X-Series audio amplifier, allowing the amplifier to meet the necessary plenum rating requirements. The AMP-PNMK is compatible with the AMP-X75, AMP-X300, and DM-NAX-AMP-X300 amplifiers.
Features
Key Features
- Enables compatible X-Series amplifiers to be installed in plenum spaces
- Connects to an IEC C14 AC power inlet to meet plenum rating requirements
- Compliant with UL 2043 Plenum Rating, CCEA Section 18‑27-300.22, NFPA70-National Electric Code
Specifications
| Connections | |
| Wire lead size | 16 AWG |
| Knockout | |
| Knockout size | 3/4 in. NPT Fitting |
| Environmental | |
| Temperature | 4° to 176° F (-15.5° to 80° C) |
| Humidity | 10% to 95% RH (non‑condensing) |
| Dimensions | |
| Height | 3.85 in. (978 mm) |
| Width | 1.67 in. (42 mm) |
| Depth | 1.58 in. (40 mm) |
| Weight | |
| 0.34 lb (0.157 kg) | |
| Compliance | |
|
Regulatory Model: ETLus-Intertek, UL-2043, WEEE |
|
