Crestron

CTN CEN-SWSFP-28 28 Port Managed Switch with Redundant Power Supply Slot

CTN CEN-SWSFP-28 28 Port Managed Switch with Redundant Power Supply Slot

MFR: Crestron MPN : CEN-SWSFP-28
SKU: CEN-SWSFP-28
$3,737.50 USD
$3,737.50 USD
Sale Sold out
Shipping calculated at checkout.

Fast & Reliable Shipping

Ships in 3–5 business days

Secure Checkout

Your information is protected

Expert Support

Call, chat or email our team

View full details
Product Information

Class-leading NETGEAR® AV network switches are designed to make integration with Crestron AV-over-IP products as simple as possible. The CEN‑SWSFP‑28 is a 28 port managed Ethernet switch with 24 10 Gigabit Base-X SFP+ ports and four 25 Gigabit Base-X SFP28 ports. All of the SFP ports enable use of transceiver modules to connect to a multimode or single-mode fiber network.

Overview

Class-leading NETGEAR® AV network switches are designed to make integration with Crestron AV-over-IP products as simple as possible. The CEN‑SWSFP‑28 is a 28 port managed Ethernet switch with 24 10 Gigabit Base-X SFP+ ports (16 at 1 Gbps/10 Gbps, 8 at 10 Gbps only) and four 25 Gigabit Base-X SFP28 ports. All of the SFP ports enable use of transceiver modules to connect to a multimode or single-mode fiber network.

DM NVX and DM NAX AV-over-IP Profiles
When configuring a DM NVX AV-over-IP or DM NAX Audio-over-IP network, select the appropriate profile to automatically configure the CEN‑SWSFP‑28 with the multicast management functionality required.

Web Browser Interface
Using a streamlined interface, quickly configure individual ports or assign AV profiles for use with DM NVX or DM NAX systems. An advanced command line interface is also available.

Modular Power Supply Slot
The CEN‑SWSFP‑28 features a modular power supply slot compatible with the CEN‑SWSFP‑PWS350 for power redundancy.

Features

Key Features
  • Class-leading NETGEAR® AV network switch
  • Rack-mount 28 port managed switch
  • One slot for modular power supply unit (sold separately)
  • Twenty-four 10 Gigabit Base-X SFP+ ports
  • Four 25 Gigabit Base-X SFP28 ports
  • Selectable DM NVX® AV-over-IP and DM NAX® Audio-over-IP profiles
  • Layer 2 and Layer 3 managed switching functionality
  • LLDP (Link Layer Discovery Protocol) support
  • 680 Gbps switching fabric (non-blocking)
  • Simple-to-use Web browser interface

Specifications

Ethernet
Ports (16) 1 Gigabit/10 Gigabit Base-X SFP+;
(8) 10 Gigabit Base-X SFP+;
(4) 25 Gigabit Base-X SFP28
Network Standards IEEE 802.3af, 802.3at
MAC Addresses Up to 16K
Switch Fabric 680 Gbps non-blocking
Lite Layer 3 Package
Management Out-of-band;
IT Web GUI (main);
HTTPs, CLI, Telnet, SSH;
SNMP, MIBs, RSPAN;
Radius users, TACACS+
IPv4/IPv6 ACL and QoS Ingress/egress;
1 Kbps shaping, time-based;
Single rate policing
IPv4/IPv6 Multicast Filtering Automated IGMP between switches;
IGMPv3 MLDv2 snooping, proxy ASM and SSM;
IGMPv1, v2 querier (compatible with v3);
Control packet flooding
IPv4/IPv6 Policing and Convergence Auto-VoIP;
Policy-based routing;
LLDP-MED;
IEEE 1588 PTPv2
IPv4/IPv6 Authentication Security Successive tiering (DOT1X, MAB, Captive portal);
DHCP snooping;
Dynamic ARP inspection;
IP source guard
IPv4/IPv6 Static Routing Port, subnet, VLAN routing;
Multicast static routes;
DHCPv4 server;
DHCP relay;
Stateful DHCPv6 Server
IPv4/IPv6 Dynamic Routing IPv4: RIP;
IPv4/IPv6: PIM-SM, PIM-DM, SSM
Spanning Tree Green Ethernet STP, MTP, RSTP;
PV(R)STP;
BPDU/STRG;
EEE 802.3az
VLANs Static, dynamic, voice, MAC;
GVRP/GMRP;
Double VLAN mode;
Private VLANs
Controls & Indicators
POWER (1) green LED, indicates operating power supplied via main power input
FAN (1) green LED, indicates fan is in operation
OOB (2) green LEDs for Ethernet port, indicates Ethernet link status for out-of-band (service) port
STACK MASTER (1) green LED, indicates that the unit is operating as stack master for its switch stack
STACK ID (1) Seven-segment green LED digit, indicates the number of the switch in its switch stack
1-28 (1) green LED per SFP+ or SFP28 port, indicates active connection
On / Off (1) Rocker switch;
Turns main power on or off
RESET (1) Recessed push button;
Used for reboot or factory reset
Connectors
OOB (1) 8-wire RJ45, female;
10/100/1000Base-T Ethernet port
USB-C USB-C® port, female
100-240V (1) power connector
PSU (1) Modular power supply slot for CEN‑SWSFP‑PWS350 (sold separately)
USB 3.0 (2) USB Type A connectors, female
1-16 (16) SFP+ ports, female;
1 Gigabit/10 Gigabit Base-X SFP+
17-24 (8) SFP+ ports, female;
10 Gigabit Base-X SFP+
25-28 (4) SFP28 ports, female;
25 Gigabit Base-X SFP28
Power Requirements
Main Power 6.3A @ 100-240VAC, 50/60 Hz
Power Consumption Full Mesh Traffic: 119.3 W;
Standby: 45.2 W
Environmental
Temperature 32° to 122° F (0° to 50° C)
Humidity 10% to 90% RH (non‑condensing)
Acoustic Noise Quiet Mode: 34 dBA at 77° F (25° C);
Cool Mode: 62 dBA at 77° F (25° C)
Construction
Chassis Metal, black finish, fan-cooled, vented sides
Mounting Freestanding or 1U 19-inch rack-mountable with reversible rack ears
Dimensions
Height 1.7 in. (43.2 mm)
Width 17.32 in. (440 mm)
Depth 15.74 in. (400 mm)
Weight
13.78 lb (6.25 kg)
Compliance
Regulatory Model: XSM4328FV
