Product Information

Provides one or more NEMA 5 type AC power outlets within a Crestron® FT2 Series FlipTop™. For use in the U.S., Canada, Mexico, and other locales. Includes two additional outlets and attached power cord below the table.

Overview

Crestron® FT2A-PWR-US Series AC Power Outlet Modules are designed for installation within a Crestron FT2 Series FlipTop™ to provide one or more NEMA 5 type receptacles above the table. Three models are offered, providing a choice of one, two, or three outlets per module. Each model also provides two additional outlets below the table. The single outlet module (FT2A-PWR-US-1) occupies two module spaces within the FlipTop, while the dual outlet module (FT2A-PWR-US-2) requires three module spaces, and the triple outlet module (FT2A-PWR-US-3) demands four module spaces.

Each FT2A-PWR-US series module is rated for 10 Amps at 125 Volts AC, 50/60 Hz and is UL® Listed. They are suitable for use in the United States, Canada, Mexico, and other countries or regions where NEMA type power outlets are used (Commerce Department Plug Type B). An 8 foot (2.44 meter) long cord with grounded plug is attached at the bottom of each module for connection to an AC power source below the table.

TAA Compliant (2)

Features

Key Features
  • Adds one or more AC power outlets to an FT2 Series FlipTop™
  • Outlets sit nearly flush at the top of the FlipTop for easy access
  • Models available with one, two, or three NEMA 5 type receptacles
  • All models include two additional receptacles below the table
  • Connects to the AC power source via an 8 ft (2.44 m) long power cord with grounded plug
  • Suitable for use in the U.S., Mexico, and other locales
  • Rated 10 Amps at 125 Volts AC, 50/60 Hz
  • UL® Listed for US
  • Simple drop-in modular design
  • Single outlet model occupies two module space within the FlipTop
  • Dual outlet model occupies three module space within the FlipTop
  • Triple outlet model occupies four module space within the FlipTop

Specifications

Power Rating
Per Outlet 10 Amps @ 125 Volts AC, 50/60 HZ
Module Total 10 Amps @ 125 Volts AC, 50/60 HZ
Receptacles & Plugs
Outlets Above Table (1, 2, or 3) NEMA 5-15R grounded AC power receptacles, Commerce Dept. Type B
Outlets Below Table (2) 18 inch (457 mm) attached cables with (1) NEMA 5-15R grounded AC power receptacle per cable
Main Power Plug (1) 8 foot (2.44 meter) attached cable with NEMA 5-15P grounded AC power plug
Environmental
Temperature 32° to 113° F (0° to 45° C)
Humidity 10% to 90% RH (non-condensing)
Construction
Composition Precision fit plastic drop-in module, black, includes inline junction capsule with attached cables beneath the table
Mounting • FT2A-PWR-US-1 requires two consecutive module spaces within the FlipTop chassis;
• FT2A-PWR-US-2 requires three consecutive module spaces within the FlipTop chassis;
• FT2A-PWR-US-3 requires four consecutive module spaces within the FlipTop chassis;
• Refer to the CAD drawing for clearances required to accommodate the inline junction capsule and cabling beneath the table
Compliance
UL® Listed for US
