Crestron® outdoor weatherproof speaker delivers high-performance audio to all corners of the property.

Overview

Crestron® Reference speakers made by Origin Acoustics deliver the pinnacle of performance for demanding outdoor installations. Select materials, top shelf components and a high-end appearance underscore the design behind each model. The result is a no-compromise outdoor speaker designed to be staked directly into the ground or mounted to an exterior wall, fence post, or tree.

The REFERENCE OD4-BRZ-T-EACH 2-way weatherproof outdoor speaker features a 4 in. (102 mm) polypropylene woofer with a coaxially mounted 0.75 in. (19 mm) PEI mylar tweeter for crisp highs with consistent coverage across a wide listening area.

Each speaker includes a 32.5 in. (826 mm) direct-burial speaker wire that is permanently attached to the speaker and routed through the mounting base for a clean, reliable installation. A suitable electrical box (not included) is advised for termination of the speaker wiring. A pair of waterproof wire nuts are included to terminate the bare wire ends.

The following accessories are available:

  • 12.43 in. (316 mm) ground stake (included) to mount and install the speaker directly into the ground
  • 17.72 in. (450 mm) ground stake (SPKA-STAKE-OD-18)
  • Tree or surface mount bracket (SPKA-SMK/TREEMK-REFERENCE-OD4) to mount the speaker to an exterior wall, fence post, or tree.

NOTE: The SPKA-STAKE-OD-18 and SPKA-SMK/TREEMK-REFERENCE-OD4 are not included.

CrestronHome (2)

Features

Key Features
  • Weatherproof 2-way outdoor speaker
  • Coaxial design for wide dispersion, larger listening area, and excellent stereo imaging with two speakers
  • Designed for landscape and wall mount applications
  • 4 in. (102 mm) polypropylene woofer
  • 0.75 in. (19 mm) PEI mylar tweeter
  • IPX6 waterproof
  • 16 Ohms nominal impedance
  • 120 W (Program), and 240 W (Peak) power handling
  • 90 Hz to 20 kHz (±3 dB) frequency response
  • 120° horizontal and vertical nominal coverage

Specifications

Features & Performance
Woofer 4 in. (102 mm) polypropylene
Tweeter 0.75 in. (19 mm) PEI mylar
Crossover 100 Hz
Crossover Point 2.5 kHz
Impedance 16 Ohms nominal
Frequency Response 90 Hz to 20 kHz (±3 dB)
Frequency Range 80 Hz to 20 kHz (±10 dB)
Power Handling (8 Ohms) Program: 120 W;
Peak: 240 W
Sensitivity 87 dB @ 1 W/1 M
Coverage 120° horizontal and vertical nominal
Connections
Direct-burial Speaker Wire 32.5 in. (826 mm)
Wire Gauge (2) 12 AWG (4 mm2)
Environmental
Temperature 4° to 176°F (-15.5° to 80°C)
Humidity 10% to 90% RH (non-condensing)
Splash Resistance IPX6 waterproof
Construction
Enclosure Color-molded composite
Baffle UV treated HDPE
Grille Electroplated and powder coated steel
Mounting Ground stake, tree or surface mount
Dimensions
Height 18.02 in. (458 mm)
Width 5.76 in. (147 mm)
Depth 7.05 in. (180 mm)
Weight
3 lb (1.36 kg)
Compliance
CE, RoHs, FCC Part 15 Class B digital device
Regulatory Model M202046015
