CTN SAROS ICT5T-22-W-T-EACH+ Saros® In-Ceiling Tile Loudspeaker (must be ordered in multiples of 2)

CTN SAROS ICT5T-22-W-T-EACH+ Saros® In-Ceiling Tile Loudspeaker (must be ordered in multiples of 2)

MFR: Crestron MPN : SAROS ICT5T-22-W-T-EACH+
SKU: SAROS ICT5T-22-W-T-EACH+
$187.50 USD
$187.50 USD
Sale Sold out
Shipping calculated at checkout.

Fast & Reliable Shipping

Ships in 3–5 business days

Secure Checkout

Your information is protected

Expert Support

Call, chat or email our team

View full details
Product Information

A ceiling mount loudspeaker designed for drop-in installation in a 2x2 or 2x4 ft ceiling grid.

Overview

Saros® speakers by Crestron® deliver professional grade performance and flexible installation in a range of popular sizes for demanding commercial applications. Solid construction, easy installation, and high-end components are hallmarks of the Saros speaker line. Ideal for use in background or foreground music, paging, and sound reinforcement systems, Saros speakers are engineered to achieve smooth, even coverage, high output, and clear, natural sound quality through the employment of horn-loaded titanium dome tweeters, high-efficiency damped cone woofers, and precisely tuned crossovers.


The Saros ICT5T-22 is a 2 ft x 2 ft ceiling mount loudspeaker designed for multimedia presentation and speech reinforcement in classrooms, meeting spaces, and most indoor distributed sound system applications. It features a coaxial 5 in. two-way driver in a low profile enclosure that’s ideal for use in plenum spaces that are packed with preexisting systems and utilities, leaving limited space for ceiling loudspeakers. A built-in 16 W multi-tap transformer allows for use with 70 and 100 V distributed speaker systems. Drop-in simplicity affords fast and easy installation in a typical 2x2 or 2x4 ft suspended ceiling grid with 15/16 in. face profile.

The Saros ICT5T delivers exceptional sound quality with wide dispersion for the greatest area of coverage. The coaxial two-way loudspeaker delivers exceptional intelligibility through the voice band. Announcements will be clear and natural sounding, and will cut through typical background noise in busy environments. Applications requiring music program will deliver full-bodied sound. The high power handling enables the loudspeaker to be mounted into tall suspended ceilings where greater volume levels are required to reach the target SPL for the listeners.

Saros ICT5T speakers are UL® 1480A and UL 2043 listed1 for use in plenum air return spaces. Saros ICT5T speakers are priced individually and sold in pairs.

Features

Key Features
  • Full-range 5 in. suspended ceiling mount loudspeaker
  • 4 in. low profile height can be installed in a crowded plenum space
  • Easy drop-in installation for 2x2 and 2x4 ft ceiling grids
  • Fully-enclosed plenum-rated housing
  • Finely-perforated white metal grille
  • Cross tee accessory provided for 2x2 and 2x4 ft applications
  • Five seismic attachment points
  • 30 W power handling in low impedance mode
  • 70 Hz to 18 kHz frequency response
  • Built-in 70/100V multi-tap transformer, with 8-ohm bypass

Specifications

Performance
Transducers 5 inch woofer with dome tweeter
Beamwidth 120°
Impedance 8 Ohms nominal with transformer set to "8-ohm"
Frequency Range 70 Hz to 18 kHz (+3/-10 dB)
Transformer Taps 1 W, 2 W, 4 W, 8 W, 16 W @ 70 V;
2 W, 4 W, 8 W, 16 W @ 100 V;
Selectable with rotary knob
Power Handling 30 W for LoZ operation
Nominal Sensitivity 90 dB at 1 W/ 1 m
Connections
Input (1) 4-pin 5 mm detachable terminal block;
Speaker input with parallel pass-thru;
Maximum Wire Size: 12 AWG
Controls
Transformer Tap (1) Rotary knob on plenum side of the loudspeaker enclosure;
Used to select 70/100 V tap or 8 Ohms (bypass)
Environmental
For indoor use only
Construction
Enclosure Steel, painted black with 5 tether attachment points
Baffle Steel, painted black
Grille Steel, painted white
Installation Lays onto suspended ceiling grid;
Ships with 1 cross tee accessory per loudspeaker, 24 in. length, 15/16 in. face profile, staked-on end clips. Two cross tees per box.
Dimensions
Height 4.00 in
Width 23.75 in
Depth 23.75 in
Weight
12.45 lb (5.6 kg)
Compliance
UL 1480A, UL 20431
